R&D OVERVIEW
Insong GE’s R&D is the future growth engine.
We contribute to the improvement of our future and life through scientific
and professional research and development, from the development of new products
for customer needs to national research.
IN-HOUSE TECHNOLOGY: LIVESTOCK MANURE TREATMENT SYSTEM
(Patent No. 0976144) Livestock manure treatment device and livestock manure treatment method
  • good quality liquid fertilizer
    Prevent sludge settling, Capable of producing high-quality liquid fertilizer in a short period of time
    Powerful aeration with high-efficiency microbubble device
    and sludge inside the aeration tank through stirring.
    Prevents sedimentation and produces good quality in a short period of time. Liquid fertilizer can be produced
  • High-speed fermentation
    High-temperature aerobic high-speed fermentation Promotable
    Chemical agents are removed using a pressure flotation device.
    Do not use non-degradable substances Separate high-temperature aerobic high-speed fermentation can promote
  • Odor capture

    Easy to capture odor, Odor reduction
    The aeration tank is designed to be sealed so that there is no odor.
    It is easy to capture and the odor generated is Reduced through deodorizer.
  • automatic sensor
    Unmanned operation using automatic sensors Management time can be minimized
    Unmanned operation using automatic sensors
    Management time can be minimized
  • Minimize noise
    Semi-permanent with STS material,Minimize breakdowns and noise with simple mechanical structure
    The main parts are semi-permanent with STS material, Simple mechanical structure minimizes faults and minimizes noise.
  • Maintenance
    Capable of installing facilities in a small area,Low maintenance costs
    Facilities can be installed in a small area, Low maintenance costs

Mass balance analysis
INLET WATER
BOD 26000
CODcr 27428.6
SS 33600
T-N 2267.3
T-P 415.1
– –
FINAL TREATED WATER
BOD 425
CODcr 1714.3
SS 1350
T-N 1377.8
T-P 97.2
Q 10
Core technology of our own technology:
Separation process of difficult-to-decompose substances and production of liquid fertilizer

Empirical study of nutrient solution (secondary processing solution ratio)
–Chonnam National University Industry
-Academic Cooperation Foundation
Project name: Performance evaluation and improvement plan of livestock manure treatment technology through high-temperature aerobic high-speed fermentation
